HARTUNG wheel 4.50Ex16 5/175 d135 ET-25
HARTUNG wheel 4.50Ex16 5/175 d135 ET-25 Wheels for agricultural machinery

HARTUNG wheel 4.50Ex16 5/175 d135 ET-25

Item number: 36.3101010-А2
Characteristics
  • Wheel disk type Wheel disks
  • Usage Посевной комплекс "Кузбасс" Кемерово
  • Recommended tire sizes 180-406(6,5-16); 170-406(6,0-16)

Characteristics

  • Wheel disk type Wheel disks
  • Usage Посевной комплекс "Кузбасс" Кемерово
  • Recommended tire sizes 180-406(6,5-16); 170-406(6,0-16)
  • Number of holes 5
  • Connection conical lug holes
  • Weight, kg 9.1
  • Central mounting hole diameter, mm 135
  • Diameter of mounting holes, mm 175
  • Diameter of mounting holes, mm 20
  • Offset ET, mm -25
  • Load, kilogram-force 750
  • Width, inches 4,50Е
  • Diameter, inches 16
